Welding Catalog 2013 - page 9

07 ELECTRO HEAT
Flux Oven
The FXA 300 is a silo for drying and storing of welding flux. The capacity is 200 kg and a maximum temperature of 300°C. Supply
volatge 230V/2KW. The FXA is equipped with 3000W heating element to provide constant heat controlled by digital temperature
controller
Holding Oven
The ED150 and SD150 is used for dry storage of welding rods can be used upto 150°C. The inside is manufactured in polished
stainless steel enabling it to be used in tough environments, digital. Removable stainless steel baskets are included.
Holding Oven
The ED220 and SD220 is used for dry storage of welding rods can be used upto 220°C. The inside is manufactured in polished
stainless steel enabling it to be used in tough environments. Removable stainless steel baskets are included. A digital
temperature controller is used for temperature adjustment.
TECHNICAL DATA
FXA 300
Supply Voltage
Power
Max Temp.
Weight
Capacity
~230V/50Hz
2000W
300°C
150kg
appr. 200kg
TECHNICAL DATA ED 150
SD 150
Supply Voltage
Power
Max Temp.
Inner Dim WxHxD
External Dim WxHxD
Weight
Capacity
1~230V/50Hz
3340W/14,5A
150°C
750x700x480mm
830x650x1160mm
160kg
300kg
1~230V/50Hz
833W/3,6A
150°C
400x500x500mm
520x620x880mm
60kg
120kg
TECHNICAL DATA ED 220
SD 220
Supply Voltage
Power
Max Temp.
Inner Dim WxHxD
External Dim WxHxD
Weight
Capacity
1~230V/50Hz
3340W/14,5A
220°C
750x700x480mm
830x650x1160mm
160kg
300kg
1~230V/50Hz
833W/3,6A
220°C
400x490x700mm
520x980x700mm
60kg
120kg
