Welding Catalog 2013 - page 14

12 TWECO
MECHANICAL BALL POINT
POSITIVE-NEGATIVE-CAM
CABLE CONNECTOR COMPLETE
CABLE CAPACITY 1/0, 2/0,
3/0Model No. 2-MPC
Stock No. 9425-1200
1 EACH
CONNECTORS 2MPC/4MPC
TWECOTONG
®
ELECTRODE HOLDERS
TWECOTONG electrode holders feature reversible top
and bottom insulators. Efficient 6-position jaw patterns
and fully insulated, protected springs. Ball-point cable
connection is also featured.
TWECO GROUND CLAMPS
A-316
SGC - 500
GC - 300
FGC - 500
A-732 A-14
Part
Stock
Amperage Body
Electrode
Cable Conn
English
Metric
Number
Number
Capacity
Alloy
Capacity
Capacity
Length
Length
A532-MC**
9110-1109
200
Copper Alloy
thru 5/32”(4,0mm)
Ball-Point thry 2/0
8-1/2”
216mm
A316-MC**
9110-1110
250
Copper Alloy
thru 3/16”(4,8mm)
Ball-Point thry 2/0
9-1/4”
235mm
A732-MC**
9110-1111
300
Copper Alloy
thru 7/32”(5,6mm)
Ball-Point thry 2/0
10”
254mm
A-14
9110-1104
350
Copper Alloy
thru 1/4”(6,4mm)
Ball-Point thry 4/0
11”
279mm
A-14-HD
9110-1105
400
Copper Alloy
thru 1/4”(6,4mm)
Double Ball-Point thry 4/0 12”
305mm
A-38-HD
9110-1106
500
Copper Alloy
thru 3/8”(9,5mm)
Double Ball-Point thry 4/0 13-1/4”
336mm
** Sold in Master Pack Boxed Quantities of 24
** Sold in Master Pack Boxed Quantities of 24
Part
Stock
Amperage Jaw
Cable Conn
English Metric
Number
Number
Capacity
Opening
Capacity
Length Length
SGC - 300
9205 - 1230
300
2”- Depth 1-3/4”
1/2” Stud Connection
9”
228mm
(50,8mm - 44,4mm)
SSGC - 500
9205 - 1250
500
2”- Depth 1-3/4”
1/2” Stud Connection
9”
228mm
(50,8mm - 44,4mm)
GC - 200
9205 - 1120
200
1”- Depth 3”
Ball-Point thru 1/0
6”
157mm
(25,4mm - 76,2mm)
GC - 300MC**
9205 - 1131
300
1-1/2”- Depth 4”
Ball-Point thru 3/0
8-1/2”
216mm
(38,1mm - 101,0mm)
GC - 500
9205 - 1150
500
2”- Depth 5-1/4”
Ball-Point thru 4/0
10”
254mm
(50,8mm - 133,0mm)
FGC - 200
9205 - 1320
200
5/8”- Depth 2”
Ball-Point thru 1/0
5”
127mm
(15,9mm - 50,8mm)
FGC - 300
9205 - 1330
300
1”- Depth 3-1/2”
Ball-Point thru 3/0
7-1/4”
184mm
(25,4mm - 88,9mm)
