30 KOIKE
REMOTE CONTROL GAS AUTO PIPE CUTTING
MACHINE
PORTABLE GAS PIPE CUTTING MACHINE, PICLE-1
The PICLE-1 is a manual operated portable pipe cutting machine with a chain
and gear drive system.
PORTABLE AUTOMATIC GAS CUTTING MACHINE, IK-12MAX3
The IK-12MAX3 is a high quality motor driven portable flame cutting machine designed to cut straight lines,
circles, and bevels with clean, sharp, smooth edges providing eight standard variations of cutting attachaments.
Effective pipe
diameter
Cutting thickness
Cutting shape
Drive method
Tip
114 600mm
Φ
(4” 24”) by
standard chain(2.4m=96”)
over 600mm
Φ
by extra chain addition
up to 50mm (2”)
Square and bevel (up to 45°)
Manual
100 series for any fuel gas
SPECIFICATIONS
Cutting capacity (thickness)
Cutting speed
Speed control
Motor
Power source
Weight
S-type: 5 100mm (1/5” 4”)
Standard: 80 800mm/min. (3” 31”) = 50Hz
100 1,000mm/min. (4” 39” = 60Hz)
Double cone reduction gear system
9W/10WAC100/200V
(unload) 1,500 rpm = 50Hz, 1,800 rpm = 60Hz
AC100/200V
11.5kg (25lbs)
SPECIFICATIONS
KOIKE
Weight:
Dimensions:
Power source:
Speed control:
Speed adjustment:
Cutting speed:
Effective pipe diameter:
Pipe thickness:
Cutting shape:
Motor:
Tips:
Lighter:
Fuse, 2A:
Chain:
Tip cleaner:
1 each of #0, 1 & 2
(102 for acetylene, 106V for LPG)
1
2
80 link 2.35m (94”) long
1 set
SPECIFICATIONS
ACCESSORIES
14 kg
Length:
270mm (11”)
Wheel track:
230mm (9”)
Height:
420mm (16”)
AC110V/120V/220V
50Hz/60Hz
SCR
By dial
100 - 700mm/min (4 - 28 inch/min)
150
Φ
- 600
Φ
mm (6 - 24”)
5 - 50mm (0.2 - 2”)
Square and bevel (up to 45°)
20W 10,000 RPM
AUTO PICLE
Weight:
Dimensions:
Power source:
Speed control:
Speed adjustment:
Cutting speed:
Effective pipe diameter:
Pipe thickness:
Cutting shape:
Motor:
Tips:
Lighter:
Fuse, 2A:
Chain:
Tip cleaner:
1 each of #0, 1 & 2
(102 for acetylene, 106V for LPG)
1
2
80 link 2.35m (94”) long
1 set
SPECIFICATIONS
ACCESSORIES
14 kg
Length:
270mm (11”)
Wheel track:
230mm (9”)
Height:
420mm (16”)
AC110V/120V/220V
50Hz/60Hz
SCR
By dial
100 - 700mm/min (4 - 28 inch/min)
150
Φ
- 600
Φ
mm (6 - 24”)
5 - 50mm (0.2 - 2”)
Square and bevel (up to 45°)
20W 10,000 RPM
AUTO PICLE
Inches
Plate
Tip Cutting Speed
Oxygen PSIG Fuel
Kerf
Thickness No.
in/min
Cutting Preheat*
PSIG Width
1/8
00
27
20
20
2.8
0.04
1/4
0
24
30
30
2.8
0.05
3/8
0
22
30
30
2.8
0.06
1/2
1
21
40
40
2.8
0.07
3/4
2
18
45
45
3.6
0.08
1
2
17
45
45
3.6
0.08
1 1/2
3
14
45
45
3.6
0.09
2
4
12.5
45
45
4.3
0.11
2 1/2
5
11
55
55
4.3
0.12
3
5
10
55
55
4.3
0.12
4
6
8
55
55
5.7
0.14
5
6
7
55
55
5.7
0.14
6
7
6
65
65
5.7
0.16
8
7
5
65
65
5.7
0.17
10
8
3
65
65
5.7
0.23
12
8
2
65
65
5.7
0.27
KOIKE CUTTING TIPS
102 ACETYLENE CUTTING TIPS
For Hand Cutting and Portable Cutting
106 LPG CUTTING TIPS
For Hand Cutting and Portable Cutting
