WIRE ROPEWINCH
All dimensions are subject to change without prior notice
HAND PALLET TRUCK
BF
2.5 ton
3.5 ton
5 ton
Capacity
Q(kg)
2500
3500
5000
Service weight
kg
70
90
105
Steering wheel
mm
ø200
ø180
ø200
Fork wheel
mm
ø80
ø75
ø84
Max. lift height
h3(mm)
185
175
195
Total height
h14(mm)
1224
1214
1240
Lowered fork height
h13(mm)
85
75
88
overall length
l1(mm)
1533/1603
1533/1603
1533/1603
Fork dimension
s/e/t
50/160/1150
50/160/1150
60/160/1150
Distance between fork-arms out side
b5(mm)
550
550
550
Distance between fork arms inside
(mm)
230
230
230
Ground clearance centre of wheel base
m2(mm)
16
16
16
Aislewidth for pallets 1000x1200 crossways
Ast(mm)
1730/1800
1730/1800
1730/1800
Aislewidth for pallets 800x1200 lengthways
Ast(mm)
1730/1800
1730/1800
1730/1800
Turning radius
Wa(mm)
1266/1336
1266/1336
1266/1336
1600KGS/3200KGS/5400KGS
800KGS
Adjustable pump cap
Adjustable straight tappet
Option; fully rubber wrapped handle Entry roller for easy operation
h14
m2
S
l1
h13
h3
wa
100
e
b5
100
t
Ast
(mm)
E
Wire Rope Winch (Aluminium Body) [Model : TLW]
MODEL
TLW008
TLW016
TLW032
TLW054
Rated lifting capacity
ton
0.8
1.6
3.2
5.4
Rated pulling capacity
ton
1.25
2.5
5
8.1
Rated advance per full stroke
mm
60
60
40
40
Lever pull at WLL
kg
25
30
50
70
Rope diameter
mm
8.3
11
16
20
Standard length of wire rope
m
20
20
20
20
Net weight without cable
kg
7
14
23
45
A
426
545
660
940
B
235
280
325
380
C
168
190
230
280
Dimensions (mm)
D
60
72
91
105
E
64
97
116
120
L1
--
80
80
80
L2
80
120
120
120
Hand
Pallet Truck
with Digital Scale
available
