MANUAL CHAIN HOIST
Characteristics
•
Capacity ranges from 0.5T to 50T.
•
Automatic double pawl braking system.
•
Double cover protection.
•
Light weight robust construction.
•
Low effort to lift maximum load.
•
Extra thick asbestos free friction discs.
•
Fully forged hooks are fitted with safety latches as standard.
•
Galvanized Zinc plated hand chain as standard.
•
Sealed bearing.
•
The hoist is fitted with high grade 80 alloy load chain.
•
Complies with EC Council Directive 2006/42/EC,
ASME B30.
Model
TLB - 005 TLB - 010 TLB - 015 TLB- 020 TLB- 030 TLB- 050
TLB-075
TLB- 100
TLB- 150
TLB- 200
TLB- 300
Model
TLB - 050
TLB - 075
TLB - 150
TLB- 300
TLB- 600
TLB- 900
Capacity
Ton
0.5
0.75
1.5
3
6
9
Standard lift
m
1.5
1.5
1.5
1.5
1.5
3
Proof load
Ton
0.75
1.12
2.25
4.5
9
13.5
Effort required to lift rated load
N
140
140
240
320
340
360
No. of falls of load chain
1
1
1
1
2
3
Load chain
mm
5x15
6x18
8x24
10x30
10x30
10x30
A
105
148
176
195
195
195
B
78
88
102
109
109
109
(Dimensions mm)
C
80
135
162
211
254
319
D
35
37
45
50
64
85
K
30
26
32.5
38
48
50
Net weight
Kg
4
7.7
11.8
21
32
56.7
Extra weight per metre of extra lift Kg
0.552
0.8
1.4
2.15
4.3
6.45
Chain Hoist [Model : TLB]
Remarks : Hoists with the lift in other length are also available
Remarks : Hoists with the lift in other length are also available
All dimensions are subject to change without prior notice
Lever Hoist [Model : TLB]
MANUAL LEVER HOIST
Characteristics
•
TOYOLIFT lever hoist is universal, manual hoist for tensioning and lashing in any direction.
•
The ratchet lever hoist features compact design and robust, deep drawn, stamped steel construction.
•
High quality materials ensure light weight without infringing reliability.
•
Asbestos free brake, holding load at any desired height.
•
Top & Bottom hooks are fitted with safety latches as standard.
•
The load chain can be pulled freely and easily through the hoist in both directions to attach the load
or to tension the chain.
•
Short hand lever with rubber grip.
•
Hand lever operates with little effort due to optimal gear ratio.
•
Drop forged steel suspension & load hooks are heat treated.
•
The hoist is fitted with high grade 80 alloy load chain.
•
Complies with EC Council Directive 2006/42/EC, ASME B30.
Capacity
Ton
0.5
1
1.5
2
3
5
7.5
10
15
20
30
Standard lift
m
3
3
3
3
3
3
3
3
5
5
5
Proof load
Ton
0.75
1.5
2.25
3
4.5
7.5
11.25
15
22.5
30
45
Effort required to lift rated load
N
200
320
360
365
385
435
435
435
435X2
435X2
435X2
No. of falls of load chain
1
1
1
1
2
2
3
4
8
8
12
Load chain
mm 6X18
6X18
8x24
8x24
8x24
10X30
10x30
10x30
10x30
10x30
10x30
A
137.5
146.5
170
170
170
190.4
190
190
209
209
312
B
137
162
183
194
220
288
377
384
625
625
691
(Dimensions mm)
C
270
317
399
414
465
618
768
798
890
890
1380
D
35
35.5
45
42.5
50
64
64
85
110
110
110
K
28
26
32.5
32
37
46
45
50
81
81
81
Net weight
Kg
9.3
11.4
16.7
18.5
21.2
41.8
61.6
81.7
209
209
292.5
Extraweight permetre of extra lift Kg
1.7
1.7
2.3
2.3
3.7
5.3
7.5
9.7
18
18
27
C
A
B
L
K
A
B
A
B
A
A
B
B
C
C
C
C
K
D
D
D
K
K
K
D
H
7.5t,10t
